Portable Air Line System

BAC-10 - 2 Worker

  1. Operates 1 hood style respirator or 2 tight fiting constant flow masks,respirator requirements CANNOT exceed maximum pressure of 15 psi.
  2. Maximum 10 psi at 9 cfm output,9.5 cfm output at 4 psi
  3. Electric motor: 3/4 HP ,ODP , 100-115/208-230 VAC ,9.2/4.8 amps, 50/60 Hz
  4. Weight: 55 lbs.

BAC-17 - 3 Worker

  1. Operates 2 hood style respirator or 3 tight fiting constant flow masks as long as combined flow requirments DO NOT exceed 15 cfrm at 4 psi.
  2. Maximum 15 psi at 12 cfm output,15 cfm output at 4 psi .
  3. Electric motor: 1.5 HP TEFC, 115/208-230 VAC ,14.4/7.2 amps, 60 Hz
  4. Optional HEPA intake filter ,order separately (BAC-20HF-1)
  5. Weight: 90 lbs.

BAC-20 - 4 Worker

  1. Operates 2 hood style respirator or 4 tight fiting constant flow masks as long as combined flow requirments DO NOT exceed 20 cfrm at 4 psi.
  2. Maximum 15 psi at 16 cfm output,20 cfm output at 4 psi .
  3. Electric motor: 2 HP TEFC, 115/208-230 VAC ,18.9/9.4 amps, 60 Hz
  4. Optional HEPA intake filter ,order separately (BAC-20HF-1)
  5. Weight: 103 lbs.

BAC-203 TCO

Portable airline system is cheap and easy to use for working in hazardous area where the air quality is not breathable widely used for maintenance and hazardous chemical/gas handling. We offer the range of compressor to work with one to four workers at the same time
